Z829A 8 pin L-shaped Locking Battery connector

This is 2+6 pin battery waterproof panel mount wire connectors with locking function, can be used on Ebike/scooter chargers.
Availability:
Quantity:
sharethis sharing button
  • HT-F-Z829A

Rated Voltage
48V/60V
Rated Current40A-5A
Withstanding Voltage700V 2mA 0.05S
Insulation Resistance≥20MΩ
Contact Resistance≤10mΩ
Mating TypePanel mount
Mating Cycles200Times
Insertion Force80N Max,Extraction 30N Min
Operation Temperature-25℃~+80℃
Protection DegreeIP67
External Diameter19.9mm
Mating Length46.6mm
Product Material,Contact elementMale:GB HPB-62-1 Gold-plated.Female:GB QSN6.5-0.1 Gold-plated/
Locating partPA66+30%GF UL94-V0 Black
Wire Section6.0mm²+0.34mm²

40A 8pin battery charging connector
